Features and Specifications
- Nominal Discharges : Available in 1.1, 1.6, 2.0 & 2.2 lph Emitter Spacing : Standard emitter spacing of 15 20, 30, 40, 50, 60, 75, 90, 100, 120 and 150 cm. Any other emitter spacing and group spacing can be supplied on demand.
- Sizes : Standard sizes of 12, 16, 17, 18, 20, 22 and 23 mm nominal diameter. Other sizes can be supplied on demand.
- Pressure Compensating Range : 0.4 to 4.0 kg/cm2 (5.7 to 56 psi)
Applications
- All purpose versatile product. Suitable for undulating and
hilly terrain.
- Recommended for Greenhouse application.
- Open field application to maintain high field application
efficiency.
- PCAS is recommended for subsurface application to prevent soil suction.
- Irrigation of large fields & long rows.
- Low operating pressure/ Gravity feed irrigation system.
|
