| Disclean® PL Filter Silver |
 |
Features and Specifications
- Radially Convergent
Grooved Discs
Disclean® element with
strong, precision engineered
and radially grooved
disc to provide fine three
dimensional filtration. (Flow
direction Out to In).
- Easy for Maintenance
Strong and smooth opening,
drip–tight SS clamp closure.
- Angular or Straight
Outlet Option Available
Optional two outlet positions
facilitates installation in
angular or straight fashion
- Equipped with Pressure
Check Assembly
To check pressure from
inlet side and outlet side,
additional Pressure check
assembly provided.
- Various Connection
Options Available
Threades connection,
Flanged connection or Easy
Fix™ connection available
- Draining Facility
Available
Additional Drain Valve
provided to remove dirt from
filter
- Manufactured from special plastic alloy material which gives
very high stiffness, toughness, heat and impact resistance.
- Excellent chemical and weather resistance.
- Ribbed body construction, designed to withstand water
hammer and surges in the pipe line.
- Maximum operating pressure 6 kg/cm² (85.2 psi).
- Available in standard filtration 130 micron. (Other mesh sizes
are available On demand)
- Available in 2" (20 & 25 m³/hr), 2 ½" (30 m³/hr) and 3"(40 &
50 m3/hr) inlet & outlet connection sizes.
- On demand, Disclean – PL can also be supplied with
automatic flushing arrangement.
Applications
- Used for water filtration of drip & landscape irrigation system
- Suitable to use where precision filtration is required like reclaimed water application.
|
|
|
